Into the breach
Yaml paths:
/gameConfigs/TBS/Ported/IntoTheBreach.yaml
Description
Based in the game developed by Subset Games. Civilian buildings power your mechs. Defend them from the enemies and watch your fire!
YAML
GameConfig:
Type: TBS
RoundLimit: 100
FogOfWar: false
Player:
Parameters:
PusherSpawn: [0,1,1]
ArcherSpawn: [0,1,1]
BomberSpawn: [0,1,1]
EnemySpawn: [0,3,3]
Agents:
- HumanAgent #ID: 0
- RandomAgent #ID: 1
GameRenderer:
Resolution:
Width: 800
Height: 600
Default Assets:
FogOfWar: ../../../assets/Tiles/notVisible.png
GridIsIsometric: true
TileSpriteOrigin:
Width: 128
Height: 112
EntitySpriteOrigin:
Width: 256
Height: 360
TileSpriteSize:
Width: 256
Height: 144
EntitySpriteSize:
Width: 512
Height: 512
#Optional:
#Font: ../../assets/arial.ttf
#OutlineShader: ../../assets/OutLine.frag
Tiles:
Plain:
Sprite: ../../../assets/Tiles/plain.png
Symbol: .
IsWalkable: true
DefaultTile: true
PlayerPlain:
Sprite: ../../../assets/Tiles/plain.png
Symbol: P
IsWalkable: true
DefaultTile: true
EnemyPlain:
Sprite: ../../../assets/Tiles/plain.png
Symbol: E
IsWalkable: true
DefaultTile: true
Water:
Sprite: ../../../assets/Tiles/water.png
Symbol: W
IsWalkable: true
Mountain:
Sprite: ../../../assets/Tiles/rock.png
Symbol: M
IsWalkable: false
Forest:
Sprite: ../../../assets/Tiles/forest.png
Symbol: F
IsWalkable: true
Board:
GenerationType: Manual
Layout: |-
. P P F . F . W
F c0 c0 E E . E W
. F P F . E . F
P P P F F . . E
. P . . F E . E
. P P F E F W E
. P P . . c0 F .
c0 M c0 M W W W W
Actions:
###Spawn actions
SpawnPusher:
Type: PlayerAction
Preconditions:
- "ResourceGreaterEqual(Source.PusherSpawn, 1)"
Cooldown: 1
Targets:
EntityTypeTarget:
Type: EntityType
ValidTargets: Pusher
#Conditions:
# - "CanSpawn(Source, EntityTypeTarget)"
TargetPosition:
Type: Position
SamplingMethod:
Type: Neighbours
Options:
Shape: AllPositions
Conditions:
- "IsWalkable(TargetPosition)"
- "IsTileType(TargetPosition, PlayerPlain)"
- "IsNotOccupiedGrid(TargetPosition, EntityTypeTarget)"
Effects:
- "SpawnEntity(Source, EntityTypeTarget, TargetPosition)"
- "ModifyResource(Source.PusherSpawn, -1)"
SpawnArcher:
Type: PlayerAction
Preconditions:
- "ResourceGreaterEqual(Source.ArcherSpawn, 1)"
Cooldown: 1
Targets:
EntityTypeTarget:
Type: EntityType
ValidTargets: Archer
#Conditions:
# - "CanSpawn(Source, EntityTypeTarget)"
TargetPosition:
Type: Position
SamplingMethod:
Type: Neighbours
Options:
Shape: AllPositions
Conditions:
- "IsWalkable(TargetPosition)"
- "IsTileType(TargetPosition, PlayerPlain)"
- "IsNotOccupiedGrid(TargetPosition, EntityTypeTarget)"
Effects:
- "SpawnEntity(Source, EntityTypeTarget, TargetPosition)"
- "ModifyResource(Source.ArcherSpawn, -1)"
SpawnBomber:
Type: PlayerAction
Preconditions:
- "ResourceGreaterEqual(Source.BomberSpawn, 1)"
Cooldown: 1
Targets:
EntityTypeTarget:
Type: EntityType
ValidTargets: Bomber
#Conditions:
# - "CanSpawn(Source, EntityTypeTarget)"
TargetPosition:
Type: Position
SamplingMethod:
Type: Neighbours
Options:
Shape: AllPositions
Conditions:
- "IsWalkable(TargetPosition)"
- "IsTileType(TargetPosition, PlayerPlain)"
- "IsNotOccupiedGrid(TargetPosition, EntityTypeTarget)"
Effects:
- "SpawnEntity(Source, EntityTypeTarget, TargetPosition)"
- "ModifyResource(Source.BomberSpawn, -1)"
SpawnEnemy:
Type: PlayerAction
Preconditions:
- "ResourceGreaterEqual(Source.EnemySpawn, 1)"
Cooldown: 0
Targets:
EntityTypeTarget:
Type: EntityType
ValidTargets: Worm
#Conditions:
# - "CanSpawn(Source, EntityTypeTarget)"
TargetPosition:
Type: Position
SamplingMethod:
Type: Neighbours
Options:
Shape: AllPositions
Conditions:
- "IsWalkable(TargetPosition)"
- "IsTileType(TargetPosition, EnemyPlain)"
- "IsNotOccupiedGrid(TargetPosition, EntityTypeTarget)"
Effects:
- "SpawnEntity(Source, EntityTypeTarget, TargetPosition)"
- "ModifyResource(Source.EnemySpawn, -1)"
###Attack actions
Attack:
Type: EntityAction
Cooldown: 1
Targets:
Target:
Type: Entity
ValidTargets: PlayerSpawnEntities
SamplingMethod:
Type: Neighbours
Options:
Shape: AllPositions
Conditions:
- "DifferentPlayer(Source, Target)"
- "InRange(Source, Target, Source.AttackRange)"
Effects:
- "Attack(Target.Health, Source.AttackDamage)"
Push: #Push enemy and if it hits another entity, deal damage also to the other entity
Type: EntityAction
Cooldown: 1
Targets:
Target:
Type: Entity
ValidTargets: Worm
SamplingMethod:
Type: Neighbours
Options:
Shape: Cross
Size: 1
#Conditions:
# - "DifferentPlayer(Source, Target)"
Effects:
- "PushAndHit(Source, Target, Target.Health, Source.AttackDamage)"
PushDistance: #Push enemy and if it hits another entity, deal damage also to the other entity
Type: EntityAction
Cooldown: 1
Targets:
Target:
Type: Entity
ValidTargets: Worm
SamplingMethod:
Type: Neighbours
Options:
Shape: Cross
Size: 3
Conditions:
# - "DifferentPlayer(Source, Target)"
Effects:
- "PushAndHit(Source, Target, Target.Health, Source.AttackDamage)"
PushBomb: #Push all enemies around a location and if any pushed entity hits another entity, deal damage also to the other entity
Type: EntityAction
Cooldown: 1
Targets:
Target:
Type: Position
SamplingMethod:
Type: Neighbours
Options:
Shape: Cross
Size: 4
Conditions:
- "OutRange(Source, Target, Source.MinAttackRange)" #Min attack distance
# - "DifferentPlayer(Source, Target)"
Effects:
- "PushAroundPositionAndHit(Source, Target, Source.Health, Source.AttackDamage)"
###Move
Move:
Type: EntityAction
Cooldown: 1
Targets:
Target:
Type: Position
SamplingMethod:
Type: Dijkstra
Options:
SearchSize: 2
AllowDiagonals: false
# Type: Neighbours
# Options:
# Shape: Circle
# Size: 1
Conditions:
- "IsWalkable(Target)"
- "IsNotOccupiedGrid(Target, Source)"
Effects:
- "Move(Source, Target)"
Entities:
Pusher:
Sprite: ../../../assets/Entities/unit_2.png
Symbol: p
LineOfSightRange: 6
Actions: [Move, Push]
Parameters:
Health: 3
AttackRange: 2
AttackDamage: 1
Archer:
Sprite: ../../../assets/Entities/unit_3.png
Symbol: a
LineOfSightRange: 10
Parameters:
Health: 2
AttackRange: 3
AttackDamage: 1
Actions: [PushDistance, Move]
Bomber:
Sprite: ../../../assets/Entities/unit_6.png
Symbol: b
LineOfSightRange: 4
Parameters:
Health: 2
AttackRange: 5
MinAttackRange: 2
AttackDamage: 1
Actions: [PushBomb, Move]
Worm:
Sprite: ../../../assets/Entities/unit_4.png
Symbol: w
LineOfSightRange: 4
Parameters:
Health: 2
AttackRange: 5
AttackDamage: 1
Actions: [Move, Attack]
City:
Sprite: ../../../assets/Entities/castle.png
Symbol: c
LineOfSightRange: 6
Parameters:
Health: 2
EntityGroups:
PlayerSpawnEntities: [Pusher, Archer, Bomber]
PlayerSpawnEntities: [Pusher, Archer, Bomber, City]
Movable: [Pusher, Archer, Bomber, Worm]
ForwardModel:
LoseConditions: #If true: Player -> cant play
EnemyHasNoWorm:
- "IsPlayerID(Source, 1)"
- "HasNoEntity(Source, Worm)"
- "ResourceLowerEqual(Source.EnemySpawn, 0)"
EnemyHasPlaceAllEnemiesBegin:
- "IsPlayerID(Source, 1)"
- "IsTick(2)"
- "ResourceGreaterEqual(Source.EnemySpawn, 1)"
EnemyHasPlaceAllEnemiesEnd:
- "IsPlayerID(Source, 1)"
- "IsTick(12)"
- "ResourceGreaterEqual(Source.EnemySpawn, 1)"
PlayerHasPlaceAllPusherBegin:
- "IsPlayerID(Source, 0)"
- "IsTick(2)"
- "ResourceGreaterEqual(Source.PusherSpawn, 1)"
PlayerHasPlaceAllBomberBegin:
- "IsPlayerID(Source, 0)"
- "IsTick(2)"
- "ResourceGreaterEqual(Source.BomberSpawn, 1)"
PlayerHasPlaceAllArcherBegin:
- "IsPlayerID(Source, 0)"
- "IsTick(2)"
- "ResourceGreaterEqual(Source.ArcherSpawn, 1)"
PlayerHasNoEntities:
- "IsPlayerID(Source, 0)"
- "HasNoEntity(Source, Pusher)"
- "ResourceLowerEqual(Source.PusherSpawn, 0)"
- "HasNoEntity(Source, Bomber)"
- "ResourceLowerEqual(Source.BomberSpawn, 0)"
- "HasNoEntity(Source, Archer)"
- "ResourceLowerEqual(Source.ArcherSpawn, 0)"
PlayerHasNoCities:
- "IsPlayerID(Source, 0)"
- "HasNoEntity(Source, City)"
PlayerTickLimit:
- "IsPlayerID(Source, 0)"
- "IsTick(16)"
##Check enemy and player spawned the enemies
##If tick is higher than 15 the enemy win
Trigger:
- OnStart:
Type: Player
Conditions:
- "IsPlayerID(Source, 0)"
Effects:
- "EnqueueAction(Source, SpawnPusher)"
- "EnqueueAction(Source, SpawnArcher)"
- "EnqueueAction(Source, SpawnBomber)"
- "EnqueueAction(Source, EndTurn)"
- OnStart:
Type: Player
Conditions:
- "IsPlayerID(Source, 1)"
Effects:
- "EnqueueAction(Source, SpawnEnemy)"
- "EnqueueAction(Source, SpawnEnemy)"
- "EnqueueAction(Source, SpawnEnemy)"
- "EnqueueAction(Source, EndTurn)"
- OnAdvance:
Type: Entity
ValidTargets: Movable
Conditions:
- "IsTileType(Source, Water)"
Effects:
- "Remove(Source)"
- OnTick:
#Type: Entity, Player, State
Type: Player
Conditions:
- "IsTick(10)"
- "IsPlayerID(Source, 1)"
Effects:
- "ModifyResource(Source.EnemySpawn, +2)"
